أخواني في الله
أحضرت لكم كتاب
Machine Elements in Mechanical Design
Sixth Edition
Robert L. Mott
University of Dayton
Edward M. Vavrek
Purdue University
Jyhwen Wang
Texas A&M University

كتاب Machine Elements in Mechanical Design - Sixth Edition M_e_i_10
و المحتوى كما يلي :


2–9 Tool Steels 51
2–10 Cast Iron 51
2–11 Powdered Metals 53
2–12 Aluminum 56
2–13 Zinc Alloys and Magnesium 58
2–14 Nickel-Based Alloys and Titanium 59
2–15 Copper, Brass, and Bronze 60
2–16 Plastics 61
2–17 Composite Materials 64
2–18 Materials Selection 76
References 81
Internet Sites Related to Design Properties of
Materials 82
Problems 83
Supplementary Problems 85
Internet-Based Assignments 86
3 Stress and Deformation Analysis 87
The Big Picture 87
You Are the Designer 88
3–1 Objectives of This Chapter 91
3–2 Philosophy of a Safe Design 91
3–3 Representing Stresses on a Stress
Element 92
3–4 Normal Stresses Due to Direct Axial
Load 93
3–5 Deformation Under Direct Axial
Load 94
3–6 Shear Stress due to Direct Shear Load 94
3–7 Torsional Load—Torque, Rotational
Speed, and Power 94
3–8 Shear Stress due to Torsional Load 96
3–9 Torsional Deformation 98
3–10 Torsion in Members Having Non-Circular
Cross Sections 98
3–11 Torsion in Closed, Thin-Walled
Tubes 100
3–12 Torsion in Open, Thin-Walled
Tubes 100
3–13 Shear Stress Due to Bending 102
Preface ix
Acknowledgments xv
PART 1 Principles of Design
and Stress Analysis 1
1 The Nature of Mechanical Design 2
The Big Picture 2
You Are the Designer 7
1–1 Objectives of This Chapter 8
1–2 The Design Process 8
1–3 Skills Needed in Mechanical Design 9
1–4 Functions, Design Requirements,
and Evaluation Criteria 10
1–5 Example of the Integration of Machine
Elements into a Mechanical Design 12
1–6 Computational Aids 13
1–7 Design Calculations 14
1–8 Preferred Basic Sizes, Screw Threads,
and Standard Shapes 14
1–9 Unit Systems 20
1–10 Distinction Among Weight, Force,
and Mass 21
References 22
Internet Sites for General Mechanical Design 22
Internet Sites for Innovation and Managing
Complex Design Projects 23
Problems 23
2 Materials in Mechanical Design 25
The Big Picture 25
You Are the Designer 26
2–1 Objectives of This Chapter 27
2–2 Properties of Materials 27
2–3 Classification of Metals and Alloys 39
2–4 Variabilty of Material Properties Data 43
2–5 Carbon and Alloy Steel 43
2–6 Conditions for Steels and Heat
Treatment 46
2–7 Stainless Steels 51
2–8 Structural Steel 51
CONTENTSiv Contents
5–8 Recommended Design and Processing
for Fatigue Loading 188
5–9 Design Factors 189
5–10 Design Philosophy 189
5–11 General Design Procedure 191
5–12 Design Examples 193
5–13 Statistical Approaches to Design 203
5–14 Finite Life and Damage Accumulation
Method 204
References 207
Internet Sites Related to Design 208
Problems 208
6 Columns 217
The Big Picture 217
6–1 Objectives of This Chapter 218
You Are the Designer 219
6–2 Properties of the Cross Section of a
Column 219
6–3 End Fixity and Effective Length 220
6–4 Slenderness Ratio 221
6–5 Long Column Analysis: The Euler
Formula 221
6–6 Transition Slenderness Ratio 222
6–7 Short Column Analysis: The J. B. Johnson
Formula 223
6–8 Column Analysis Spreadsheet 226
6–9 Efficient Shapes for Column Cross
Sections 227
6–10 The Design of Columns 229
6–11 Crooked Columns 232
6–12 Eccentrically Loaded Columns 233
References 237
Problems 237
PART 2 Design of a Mechanical
Drive 241
7 Belt Drives, Chain Drives,
and Wire Rope 244
The Big Picture 244
You Are the Designer 246
7–1 Objectives of This Chapter 246
7–2 Kinematics of Belt and Chain Drive
Systems 246
7–3 Types of Belt Drives 251
7–4 V-Belt Drives 252
7–5 Synchronous Belt Drives 262
3–14 Shear Stress Due to Bending – Special
Shear Stress Formulas 103
3–15 Normal Stress Due to Bending 104
3–16 Beams with Concentrated Bending
Moments 105
3–17 Flexural Center for Beam Bending 110
3–18 Beam Deflections 110
3–19 Equations for Deflected Beam Shape 112
3–20 Curved Beams 113
3–21 Superposition Principle 120
3–22 Stress Concentrations 122
3–23 Notch Sensitivity and Strength Reduction
Factor 129
References 129
Internet Sites Related to Stress and Deformation
Analysis 129
Problems 129
4 Combined Stresses and Stress
Transformation 142
The Big Picture 142
You Are the Designer 143
4–1 Objectives of This Chapter 144
4–2 General Case of Combined Stress 144
4–3 Stress Transformation 145
4–4 Mohr’s Circle 150
4–5 Mohr’s Circle Practice Problems 157
4–6 Mohr’s Circle for Special Stress
Conditions 159
4–7 Analysis of Complex Loading
Conditions 164
Reference 164
Internet Sites Related to Stress
Transformation 164
Problems 165
5 Design for Different Types
of Loading 166
The Big Picture 166
You Are the Designer 168
5–1 Objectives of This Chapter 168
5–2 Types of Loading and Stress Ratio 168
5–3 Failure Theories 172
5–4 Design for Static Loading 173
5–5 Endurance Limit and Mechanisms
of Fatigue Failure 175
5–6 Estimated Actual Endurance Limit, sn= 178
5–7 Design for Cyclic Loading 185Contents v
